液体电阻起动柜

一、       概述

高压交流电动机液态软起动柜适用于额定电压为3~10KV大、中型同步或异步电动机的软起动。在静态工作条件下，与电抗器性能相同；在动态工作条件下，可实现无级的连续起动。由于其利用液体电阻的负温度特性，使电机的端电压逐步上升，起动转矩也逐步增加，因而电机起动比较平稳。特别是该系统结构简单、可靠性强，不仅经济实用，而且安装和操作简单、维护方便。
它广泛应用于冶金、建材、矿山、石化、供水、电力行业等的泵类、风机、压缩机、破碎机、皮带传输机等各大、中容量高压电机的重载起动，是传统的电抗器降压起动、直接起动的理想的替代产品。
二 工作原理
该装置是在电机定子回路中串可变液体电阻的一种降压起动方式，即随着主电动机的起动，装置自动改变液体电阻动、定极板之间的间距，使电阻线性均匀减小，电机端电压均匀提高的一种起动方式。
主机起动结束后，软起动装置从主回路中完全脱离或处于零电位，活动极板自动复位，为下次起动作好准备。

Supply water resistance ark soft start

An overview,

High voltage ac motor soft starter liquid tank is suitable for the rated voltage is 3 ~ 10 kv large and medium-sized synchronous or asynchronous motor soft start. Under the condition of static work, the same as the reactor performance; Under the dynamic working conditions, and can realize stepless continuous starting. Due to the use of negative temperature characteristic of liquid resistance, the voltage of the motor is gradually increased, the starting torque is also gradually to increase, thus the motor starting smoothly. The system has simple structure, high reliability, in particular, not only economic and practical, and installation and simple operation, convenient maintenance.

It is widely used in metallurgy, building materials, mining, petrochemical, water supply, power industry pump, fan, compressor, such as crusher, belt transmission machine and so on each big, overload capacity of high voltage motor starter, is a traditional reactor step-down starting, direct starting the ideal alternative products.

Working principle of the two
