optical spherical lens

点击图片查看原图
品牌: VY
单价: 0.01元/piece
起订: 100 piece
供货总量: 100000 piece
发货期限: 自买家付款之日起 3 天内发货
所在地: 吉林 长春市
有效期至: 长期有效
最后更新: 2015-09-24 21:34
浏览次数: 1447
询价
公司基本资料信息








产品详细说明
 Plano-Convex Lens is widely use in optical display systems, projection optics systems, imagining optical systems, and laser measurement systems. It is best use wher conjugate point-- object distance, S or image distance S' is more than five times of the other. This lens is almost the most super form for both collimating a point source and focusing collimated light;
Plano-Concave Lens has a negative focal length and is typically used to cause a collimated beam to diverge as in a Galilean type beam expander or Telescope. Because the spherical aberration of the Plano-Concave is negative, it can be used to balance the aberration of other lenses.This lens is widely use in optical display systems, projection optics systems, imaging and laser measureemnt systerms;
Double-Convex Lens, also named Bi-Convex Lens, is most suitable wher the object and image are on opposite sides of the lens and the ratio of the image and object (conjugate ratio) distances is between 0.2 to 5. It is used in beam expanders,. Projection optics systems, optical viewers etc;
Double-Concave Lens, also named Bi-Concave Lens, is used to divergent light. The Bi-Concave is best used when the input beam is converging. It is used in beam expanders,. Projection optics systems, optical viewers and optical charater readers etc;
Meniscus Lens can increase the NA of the system while only adding slightly to the total spherical aberrations. The Negative Meniscus Lens is used to increase the focal length of another lens while maintaining the angular resolution of the optical assembly. This lens shape is best used when one conjugate is relatively far from the lens.We supply optical spherical lenses,include plano-convex spherical lens,plano-concave spherical lens,bi-convex spherical lens,bi-concave spherical lens,meniscus spherical lens,special spherical lens etc..
Specification of our plano-convex spherical lenses as follow:
*Material:BK7 or other materials
*Focal length:+/-1%
*Center thickness tolerance:+/-0.01mm
*Centration:1 arc minutes
*Surface Figure:lambda/2 at 633nm on plano side
*Surface quality:40/20 stratch/dig
*Clear Apenture>90%
*Chamfer Protective:0.25mm at 45 degree typical
*Coating:optional
