检测距离
Sensing range 0…10cm
输出功能
Output function 0-10V
工作电压
Operating voltage 10-30VDC
电流负载
Load Current 200mA
光源
Emission Infrared(880nm)
响应时间
Response time DC＜2ms
电流消耗
Current consumption DC＜15mA
指向角
Directional object 3°…10°
检测物体
Detected object Transparent or opaque body
工作环境照度
Intensity of illumination of working environment Sunlight under 10000LX,incandescent lamp under 3000LX
外壳材料
Housing material metal
环境温度
Ambient temperature -25…80℃
外壳防护等级
Protection grade IP65
开关状态
Switching status 红色 Red LED
符合标准
Certification standard CE
