| 系列 | 型号 | 电压(V) | 容量(AH) | 长(L)MM | 宽(W)MM | 高(H)MM | 总高(TH)MM | 重量约(KG) |
| NP系列 (普通应用) | NP1-6 | 6 | 1 | 51 | 42.5 | 51 | 54.5 | 0.25 |
| NP4-6 | 6 | 4 | 70 | 47 | 102 | 106 | 0.85 | |
| NP10-6 | 6 | 10 | 151 | 50 | 94 | 97.5 | 2 | |
| NP0.8-12 | 12 | 0.8 | 96 | 25 | 61.5 | 61.5 | 0.35 | |
| NP1.2-12 | 12 | 1.2 | 97 | 48 | 51 | 54.5 | 0.6 | |
| NP2-12 | 12 | 2 | 150 | 20 | 89 | 89 | 0.7 | |
| NP2.3-12 | 12 | 2.3 | 178 | 34 | 60 | 64 | 0.94 | |
| NP2.6-12 | 12 | 2.6 | 134 | 67 | 60 | 64 | 1.1 | |
| NP7-12 | 12 | 7 | 151 | 65 | 94 | 97.5 | 2.7 | |
| NP24-12 | 12 | 24 | 175 | 166 | 125 | 125 | 8.65 | |
| NP38-12 | 12 | 38 | 197 | 165 | 170 | 170 | 13.8 | |
| NP65-12 | 12 | 65 | 350 | 166 | 174 | 174 | 22.8 | |
| NP100-12 | 12 | 100 | 407 | 172.5 | 210 | 240 | 35 | |
| NPL系列 (长寿命) | NPL24-12 | 12 | 24 | 175 | 166 | 125 | 8.65 | |
| NPL38-12 | 12 | 38 | 197 | 165 | 170 | 13.8 | ||
| NPL65-12 | 12 | 65 | 350 | 166 | 174 | 22.8 | ||
| NPL100-12 | 12 | 100 | 407 | 172.5 | 240 | 39 | ||
| NPL200-6 | 6 | 200 | 397 | 175.6 | 249 | 39 | ||
| NPH系列 (高率放电) | NPH2-12 | 12 | 2 | 68 | 51 | 88 | 0.84 | |
| NPH3.2-12 | 12 | 3.2 | 134 | 67 | 60 | 64 | 1.4 | |
| NPH5-12 | 12 | 5 | 90 | 70 | 106 | 2 | ||
| UXH系列 (长寿高率) | UXH100-12 | 12 | 100 | 407 | 172.5 | 210 | 240 | 39 |
| UXH65-12 | 12 | 65 | 350 | 166 | 174 | 174 | 22.8 | |
| UXH200-6 | 12 | 200 | 398 | 176 | 215 | 249 | 39 |
