lappkabel cat 5类通讯线

LAPPKABEL UNITRONIC® LAN 200 - CAT.5e模拟数据信号电缆建筑物布线LAN电缆，符合EN 50173和ISO/IEC 11801
应用范围
主要用于终端密度非常高的场合，如第三方区域内的办公室，行政楼，新社区楼等的楼层布线
根据 ISO / IEC 11801 和 EN 50173 标准， 第三级区域（水平区域，地面）内的电缆长度总和不得超过 100 m （电缆管道内长度 90 m + 工作区域长度 10 m）
LAPPKABEL UNITRONIC® LAN 200 - CAT.5e产品最小弯曲半径
安装期间： 8 x 外径
LAPPKABEL 固定安装: 4 x 外径
UNITRONIC® LAN 200 - CAT.5e温度范围
工作温度： -20°C 至 +60°C
安装期间： 0 °C 至 +50 °C
LAPPKABEL UNITRONIC® LAN 200 - CAT.5e特性阻抗
100 Ohm +- 15%
LAPPKABEL UNITRONIC® LAN 200 - CAT.5e电缆结构
U/UTP: 无屏蔽
F/UTP: 全面铝箔屏蔽
SF/UTP: 整体铜丝编织加铝箔屏蔽
LAPPKABEL UNITRONIC® LAN 200 - CAT.5e实心导体
PVC 或 LSZH 外护套
LAPPKABEL UNITRONIC® LAN 200 - CAT.5e技术认证
ISO / IEC 11801 的 D 级标准符合 CAT.5
LAPPKABEL UNITRONIC® LAN 200 - CAT.5e适用于“建筑物布缆系统”的缆普LAN CAT.5e线缆符合EIA / TIA-568，TSB36和ISO / IEC 11801或EN 50173(D级)的要求。
LAPPKABEL UNITRONIC® LAN 200 - CAT.5e产品特征
数字和模拟数据信号的传输
这款电缆的阻抗为 100 Ohm ±15 %
IEEE 802.3: 10/100/1000Base-T IEEE 802.5: ISDN; FDDI; ATM
