橡胶电缆产品型号Product type：H05RN-F
产品结构示意图Structure sketch map
1执行标准Reference standard：DIN VDE 0282-4；HD 22.4
2适用范围：本产品适用于交流额定电压300/500V及以下动力，家用电器、电动工具和各种
移动式电气设备和工具用电缆。
Applicable scope:Rated voltage 300/500V or below. Applied in electrical appliance, electromotive tools,
all kind of movable electric equipments and implemental cable.
3电缆特性Cable characteristic:
电缆长期允许工作温度应不超过60℃。
电缆具有一定的耐候性和一定的耐油能力，适用于户外或接触油污的场合。
电缆具有阻燃性，达到HD 405.1单根垂直燃烧要求。
电缆在20℃时，绝缘线芯间绝缘电阻达50MΩ.km以上。
- Cable working temperature should not exceed 60℃
- Cable have a certain extent of temperature resistance and oil resistance, fit to work outside
and work in the smeary environment.
- Reach standardHD 405.1vertical flame test.
- When cable in temperature of 20℃the insulation resistance between conductors above
50MΩ.km.
4结构数据及主要性能Structure data and primary capability
|
规格 specification |
导体结构 Conductor |
绝缘标 称厚度 Normal thickness of insulation mm |
护套标 称厚度 Normal thickness of jacket mm |
电缆外径 Over diameter mm |
20℃时导 体电阻 Max conductor resistance at 20℃ ≤Ω/km |
载流量 Ampere rating A |
|
|
芯数 No. of core |
标称截面 normal cross-sectional area of conductor mm2 |
根数/直径 No. / Dia. mm |
|||||
|
2 |
0.75 |
24/0.20 |
0.6 |
0.8 |
6.1～7.0 |
26.0 |
14 |
|
1.0 |
32/0.20 |
0.6 |
0.9 |
6.6～7.3 |
19.5 |
17 |
|
|
3 |
0.75 |
24/0.20 |
0.6 |
0.9 |
6.7～7.6 |
26.0 |
12 |
|
1.0 |
32/0.20 |
0.6 |
0.9 |
7.0～7.9 |
19.5 |
14 |
|
