点击图片查看原图
|
型号 |
价格 |
尺寸 |
||
|
W |
T |
H |
||
|
CL21X 473J63VF |
0.12 |
6.8 |
3.3 |
5.6 |
价格仅供参考，以报价单为准。
特点及用途/Features and Applications
采用超薄超窄的金属化聚脂薄膜作介质
两端面喷金形成无感结构
CP线单向引出
阻燃环氧树脂粉末包封
体积小、重量轻，损耗小
自愈性好、可靠性高
适合于直流和脉动电路中
With thickness least and width less metallized polyester film dielectric
Twain section spray-metal form Non-inductive construction
Electrode with CP lead unilateralism fetch out and flame retardant
Epoxy resin powder coating
Small size, Light weight. Low dissipation factor
Excellent self-healing property and reliability
It is suitable for the DC and pulsating circuits
技术要求/Specifications
|
引用标准 Referedce Standard |
GB 7332（IEC 60384-2） |
|||
|
温度范围 Temperature range |
-40℃～+85℃ |
|||
|
额定耐压 Rated Voltage |
50VDC.63VDC.100VDC.200VDC |
|||
|
容量范围 Capacitance range |
0.0001μF to 1.0μF |
|||
|
容量偏差 Capacitance Tolerance |
±5%(J), ±10%(K) |
|||
|
损耗角正切 Dissipation factor |
1.0%max.(20℃ 1KHz) |
|||
|
耐电压 Voltage proof |
1.6UR (5S) |
|||
|
绝缘电阻 Insulation resistance |
C≤0.33μF |
C＞0.33μF |
||
|
UR≤100V |
UR＞100V |
UR≤100V |
UR＞100V |
|
|
≥18000MΩ |
≥15000MΩ |
≥6000MΩ.μF |
≥5000MΩ.μF |
|
此产品关键字：
精密电容器、小型电容器、无感电容
