1.
电梯电缆,偏平电缆拖拖链电缆 应用范围:
频繁弯曲场合,如:木工机械、机床加工设备、机器人系统、工业自动化场合、物流输送系统、起重机械场合等
Applications:
It is suitable for wet rooms and installation without strong stress or free
continuous
reciprocating
movement. It is special suitable for the working places of Woodworking Machine,
machine tool
equipment ,logistics conveyer system, crane and other related equipments.
拖链 电缆的特性:防水、防油、耐寒、抗紫外线、耐磨、阻燃、抗拉
弯曲寿命600万次以上不断芯
Properties:
Watproofing; oil resistance; cool resistance; abrasion resistanve; flame
resistance;anti-
ultraviolet.Bendin
for life:above 6,000,000
拖链 电缆结构
1.导体:多股超细精绞无氧铜丝,符合VDE0295 6类标准。
2.绝缘:丁晴混合弹性料、TPE混合料、PUR(按客户指定)
3.颜色:≤0.5mm颜色表示:棕、黑、蓝、红、紫、白、橙
>0.5mm颜色表示:黑色数字白色码编号,3芯以上带黄绿接地线(可选黄色)
4.护套:丁晴混合弹性料、TPE混合料、PUR或PVC(按客户指定)
颜色:黑色、灰色、橙色
额定电压:截面≤0.5mm2;300/300V,>0.5mm;300/500V
测试电压:2500V
使用温度范围:固定安装:-30至+90℃
移动安装:-20至+90℃
最小弯曲半径:固定安装5×D(电缆直径)
移动安装:当行程<10米时,弯曲半径为8×D
当行程≥10米时,弯曲半径为10×D
Structure:
Conductor:Fine strands or oxygen-free copper wire, acc. to VDE0295CLASS6
Insulation: TPE/PUR
Colour:≤0.5mm brown, biack, blue,qurple, pink, orange
≥0.5mm Cores black with consecutive white numbering. 3cores or more with
green/yellow
earth wire.
Sheath:special PVC; black or grey
Related voltage:SQ<0.5 mm2: 300/300V SQ>0.5
mm2: 300/500V
Test voltage:2500V
The working temperature: fixed installation:-30℃~+90℃
moved installation:-20℃~+90℃
